References
![](https://marelli.be/wp-content/uploads/2022/01/MHD-AXML-125-AISI-45kW-300x225.jpg)
Sector:Motorway tunnel
Country:Belgium
Type:Axial fan MHD-AXML 125 16/40 ex.4 AISI316L, motor 45kW 4P, with inlet register with servomotor and outlet non-return valve. Use : motorway tunnel.
Application:
Working point:80.000 m³/h @ 700 Pa
![](https://marelli.be/wp-content/uploads/2019/01/MMA-AF-1-273x300.png)
Sector:Stone quarry
Country:Belgium
Type:High-pressure fan MMA-AF 630/B T 5,5Kw 2P ex.4 LG0°, with 100% welded casing, shaft seal, inspection door,... Use : supply of fresh air into ovens.
Application:
Working point:1.500 m³/h @ 7.000 Pa
![](https://marelli.be/wp-content/uploads/2022/01/MMA-BC-450-ex9-RD90°-300x225.jpg)
Sector:Brickyard
Country:Belgium
Type:Centrifugal fan MMA-BC 450 2,2kW T ex.9/W RD90°, designed for air up to +300°C.
Use : supply of fresh air into furnace.
Application:
Working point:6.000 m³/h @ 390 Pa
![](https://marelli.be/wp-content/uploads/2022/01/MMA-AE-500S-ex12W-anti-etincelle-300x225.jpg)
Sector:Chemical industry
Country:Belgium
Type:High-pressure fan MMA-AE 500/S 1,5kW 2P ex.12/W, special construction : anti-spark, labyrinth sealing, fully welded casing. Application : extraction of air with oxygen.
Application:
Working point:350 m³/h @ 400 mmCE
![](https://marelli.be/wp-content/uploads/2019/01/MMA-AB-1-247x300.jpg)
Sector:HVAC units producer
Country:Belgium
Type:High-pressure MMA-AB 560/S T 18,5kW 2P fan. Application : mobile air conditionning units.
Application:
Working point:7.000 m³/h @ 6.700 Pa
![](https://marelli.be/wp-content/uploads/2019/01/MMA-AF-1-273x300.png)
Sector:Recycling of charcoal
Country:Belgium
Type:Medium pressure centrifugal fan MMA-AF 800/A T 30kW ex.4 RD45°
Fully welded casing, with inspection door, PTFE shaft sealing and G4 inlet filter.
Application:
Working point:5.150 m³/h @ 1.250 daPa
![](https://marelli.be/wp-content/uploads/2018/09/00119-293x300.jpg)
Sector:Charcoal producer
Country:Belgium
Type:Side channel blower MES-Unijet 1000 11kW.
With 11kw motor 2 poles 400V 50Hz, delivered with inlet filter and relief valve.
Application:
Working point:920 m³/h @ 1.500 mmH20
![](https://marelli.be/wp-content/uploads/2018/09/00116-295x300.jpg)
Sector: Paper industry
Country:Belgium
Type:Blower MES-MedioJet 2,2kW 400/690V.
Application : Vacuum systems
Application:
Working point:Débit max 350 m³/h. Pression max +195 mBar
![](https://marelli.be/wp-content/uploads/2018/09/00021-300x227.jpg)
Sector:Paper and corrugated board producer
Country:Belgium
Type:Belt driven ventilator MEV-TFc 901 T 'shred' ex.12 LG90/Z, motor 22kW 4P, with adapter to be used as a paper shredder.
Application : Aspiration and shredding of paper shavings
Application:
Working point:3.600 m³/h @ 775 mmH20
![](https://marelli.be/wp-content/uploads/2018/08/00030-300x300.jpg)
Sector:Milling
Country:Belgium
Type:Centrifugal fan MEV-TF 801/A ex.4, motor 15kW 2P, impeller with open blades.
Application : Pneumatic transport of flower
Application:
Working point:1.200 m³/h @ 1.200 mmH20
